Service Sheet For Service A (15,000 Mi) Or Service B (30,000 Mi) - AP00.20-D-1557TS

Model 907 with engine 274

with code JI8 (Starting distance for maintenance interval 15,000 miles)

with code ZU8 (National version for USA)

Customer.............................................

VIN/license plate number.............................................

Completion time/date.............................................

Notes/explanations.............................................

The following activities are hereby confirmed:

Completion of relevant service operations

Order number.............................................

Current mileage.............................................

Signature.............................................

A	B		Input condition not OK:	ⓧ
Completed
■	■

		Service reception
□	□	The complete reception report for service on the vehicle is available.	............... Model 907 To be performed by the Service Advisor (where market-specific conditions require). The service scope is only completely performed when all acceptance items and the maintenance items listed in the service sheet have been fully processed.	◦	AP00.20-D-0009TS
		Brake system
□	□	Perform brake test and enter result in table	...............		AP42.00-D-4290TS
		Vehicle exterior
	□	Check exterior lighting for proper operation.	...............	◦	AP82.10-D-8252TS
	□	Check headlamp range adjustment for proper operation.	...............	◦
□	□	Correct tire pressure, including spare wheel and enter adjusted tire pressure into table.	...............		AP40.15-D-4060TS
		Vehicle interior
	□	Check windshield wipers, rear window wiper, windshield washer system and headlamp cleaning system for proper operation.	...............	◦
□	□	Check seat belts, seat belt buckles and seat belt buckle extensions on driver's seat and front passenger seat for external damage and proper function.	...............	◦	AP82.30-D-82521S
			If components are damaged, ↓ Replace damaged parts with new parts. After obtaining special order.		AP91.40-D-9150TS
	□	Check first-aid kit (soft sided).	............... Enter expiration date for first-aid kit (soft sided) here:	◦
	□	Check water drain bores in floor area of sliding door.	............... With CODE T16 (Right sliding door) or with CODE T19 (Left sliding door)	◦	AP72.00-D-7254TS
		Engine compartment
□	□	Engine: Change oil and oil filter.	............... Mercedes-Benz oil recommended.		AP18.00-D-0101TSC
□	□	Brake system: Check fluid level.	...............	◦	AP42.10-D-4210TS
□	□	Windshield washer system: Check/correct fluid level	...............	◦	AP82.35-D-8210TS
	□	Check poly-V-belt in visible area for wear and damage.	............... If poly-V-belt is damaged, ↓ replace poly-V belt. After obtaining special order.	◦	AP13.22-D-1351TSC
	□	Check all visible parts in engine compartment for damage and leaks.	............... If fluid loss or damage is present, ↓ determine cause and correct. After obtaining special order.	◦	AP00.20-D-0053TS
		Underside of vehicle
	□	Check all visible parts of vehicle underside for damage and leaks.	............... If fluid loss or damage is present, ↓ determine cause and correct. After obtaining special order.	◦	AP00.20-D-0054TS
	□	Check tie rod and drag link ball joints for play, check boots.	............... If parts are damaged, ↓ determine cause and correct. After obtaining special order.	◦	AP46.00-S-4651E
	□	Check propeller shaft and flex disks.	............... If components are damaged, ↓ determine cause and correct. After obtaining special order.	◦	AP41.10-S-4152E
	□	Check suspension struts or shock absorber springs and auxiliary rubber springs.	............... If components are damaged, ↓ determine cause and correct. After obtaining special order.	◦	AP32.25-S-3255E
	□	Check tires for damage and crack formation, and enter result in table.	............... If tires are damaged, ↓ determine cause and correct. After obtaining special order.	◦	AP40.10-S-4051E
		Underside of vehicle Z = Additional operations for Service A
□		Check air suspension bellows for damage.	............... with code CB2 (Air suspension comfort suspension) If air suspension bellows are damaged, ↓ Determine cause, rectify it and replace damaged parts. After obtaining special order.	◦
		Engine compartment/vehicle interior Z = Additional operations for Service A
□		Auxiliary battery: Check/correct fluid level.	............... Only if fleece battery not installed. With code E2I (Auxiliary battery for retrofit consumer, interior) or with code E2M (Auxiliary battery for retrofit consumer, engine compartment)	◦
□		Check seat belts, seat belt buckles and seat belt buckle extensions in the rear passenger compartment for external damage and proper function.	............... Model 907 If components are damaged, ↓ Replace damaged parts with new parts. After obtaining special order.	\|	AP91.40-D-9150TS
		Underside of vehicle Z1 = Additional operations at 1st Service B, then every 75,000 mi
□	□	Automatic transmission: Change oil and oil filter.	............... Transmission 725.0 Mercedes-Benz oil recommended.		AP27.00-D-2702TSC
		Vehicle exterior Z = Additional operations for Service B
	□	Lubricate hinges of rear-end doors.	............... With code W54 (Rear-end door, two-wing, 270 degrees)		AP72.00-D-7225TS
		Vehicle interior Z = Additional operations for Service B
	□	Replace dust filter for heater/ventilation.	............... With CODE H81 (Ventilation system with filter) Replace after 2 years at the atest. Note the installation date; refer to the confirmations in the maintenance booklet or DSB!		AP83.00-D-8381TS
	□	Replace activated charcoal particle filter for air conditioning system.	............... With code HH4 (THERMOTRONIC automatic air conditioning) or with code HH9 (TEMPMATIC semi-automatically regulated air conditioning) Replace at latest after 2 years. Note the installation date; refer to the confirmations in the maintenance booklet or DSB!		AP83.00-D-8381TS
	□	Replace dust filter for roof-mounted air conditioning system.	............... With code H08 (Roof-mounted air conditioning system, uprated) or with code HH7 (Roof-mounted air conditioning system, basic) or with code HK4 (Rear air conditioning system, uprated)		AP83.50-D-8386TS
	□	Check seat belts, seat belt buckles and seat belt buckle extensions in the rear passenger compartment for external damage and proper function.	............... Model 907 If components are damaged, ↓ Replace damaged parts with new parts. After obtaining special order.	◦	AP91.40-D-9150TS
		Engine compartment/vehicle interior Z = Additional operations for Service B
	□	Auxiliary battery: Check/correct fluid level	............... Only if fleece battery not installed. With code E2I (Auxiliary battery for retrofit consumer, interior) or with code E2M (Auxiliary battery for retrofit consumer, engine compartment)	◦
		Underside of vehicle Z = Additional operations for Service B
	□	Check air suspension bellows for damage.	............... with code CB2 (Air suspension comfort suspension) If air suspension bellows are damaged, ↓ Determine cause, rectify it and replace damaged parts. After obtaining special order.	◦
		Engine compartment ZA = Additional operations (Service A or B) every 30,000 mi or every 3 years
□	□	Replace spark plugs.	...............		AP15.10-D-1580TSC
		Engine compartment ZB = Additional operations (Service A or B) every 45,000 mi or every 3 years
□	□	Replace air filter element.	............... Note the installation date; refer to the confirmations in the maintenance booklet or DSB! Air filter insert replaced ___ Yes ___ No.		AP09.10-D-0980TSC
		Engine compartment ZC = Additional operations (Service A or B) every
□	□	75,000 mi or every 4 years replace poly-V belt.	...............		AR13 22-D-1202TSC
		Engine compartment J2 = Additional operations every 2 years
□	□	Hydraulic brake system: Replace brake fluid.	...............		AP42.00-D-4280TS
		Underside of vehicle J10 = Additional operations every 10 years or 180,000 mi
□	□	Rear axle: Change oil.	............... Mercedes-Benz oil recommended.	1	AP35.00-D-3501TSR
		Engine compartment J15 = Additional operations every 15 years or
□	□	225,000 mi Replace coolant.	............... Pay attention to composition of coolant!		AP20.00-D-2080TSC

BRAKE VALUES IN KN

	Left	Right
Front
Rear
Parking brake

Remaining brake lining thickness approx. in mm
	Left	Right
front
Rear

TIRE CONDITION

	Right front	Left front	Right rear	Left rear
Condition OK.
Condition not OK.

SET TIRE PRESSURE IN BAR OR PSI

	Front axle	Rear axle	Spare wheel
bar/psi
