Antenna Feeder No. 3 Inspection
WARNING: This page is about a different car, the 2016 Mazda CX-5. However, it is still accessible from the selected car via links, so may be relevant.
- Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION .)
- Remove the following parts:
- Front scuff plate (See FRONT SCUFF PLATE REMOVAL/INSTALLATION .)
- Rear scuff plate (See REAR SCUFF PLATE REMOVAL/INSTALLATION .)
- B-pillar lower trim (See B-PILLAR LOWER TRIM REMOVAL/INSTALLATION .)
- Front seat belt adjusting cover (See FRONT SEAT BELT REMOVAL/INSTALLATION .)
- Front seat belt upper anchor installation bolt (See ADJUSTER ANCHOR REMOVAL/INSTALLATION .)
- B-pillar upper trim (See B-PILLAR UPPER TRIM REMOVAL/INSTALLATION .)
- Rear seat cushion (See REAR SEAT CUSHION REMOVAL/INSTALLATION .)
- Trunk side upper trim (See TRUNK SIDE TRIM REMOVAL/INSTALLATION .)
- D-pillar trim (See D-PILLAR TRIM REMOVAL/INSTALLATION .)
- C-pillar trim (See C-PILLAR TRIM REMOVAL/INSTALLATION .)
- Remove the rear passenger's assist handle. (See ASSIST HANDLE REMOVAL/INSTALLATION .)
- Partially peel back the headliner.NOTE:
- If the headliner is peeled back excessively, the headliner could become creased. Be careful not to peel back the headliner excessively.
- Disconnect antenna feeder No. 2.
- Disconnect the roof antenna connector.
- Disconnect the glass antenna.
- Verify that the continuity between antenna feeder No. 3 terminals is as indicated in the table.
- If not as indicated in the table, replace antenna feeder No. 3.
