Parking Brake Switch: Installation

WARNING: This page is about a different car, the 2008 Lexus IS F. However, it is still accessible from the selected car via links, so may be relevant.
  1. INSTALL PARKING BRAKE SWITCH ASSEMBLY
    1. Install the parking brake switch assembly to the parking brake control pedal assembly with the screw

      Torque: 0.9 N*m (9 kgf*cm, 8 in.*lbf)

    2. Install the tension spring to the parking brake control pedal assembly.
    Fig 1: Locating Screw
    G05752913Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
  2. INSTALL PARKING BRAKE CONTROL PEDAL ASSEMBLY
    1. Install the parking brake control pedal assembly and temporarily tighten the 3 nuts.
    2. Fully tighten the 3 nuts in the order shown in the illustration.

      Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf)

    3. Connect the parking brake switch connector.
      Fig 2: Identifying Nuts Tightening Sequence
      G05752864Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    4. Connect the instrument panel junction block assembly with the 2 nuts.
    5. Install the parking brake control pedal assembly to the body with the 3 nuts.
    Fig 3: Locating Instrument Panel Junction Block Assembly Nuts
    G05297352Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
    Fig 4: Locating Parking Brake Control Pedal Assembly Nuts
    G05752910Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

    Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)

  3. INSTALL NO. 2 REAR AIR DUCT
  4. INSTALL REAR AIR DUCT GUIDE LH
  5. INSTALL FRONT FLOOR SILENCER PAD LH
  6. INSTALL NO. 3 DASH PANEL INSULATOR PAD  (See INSTALLATION )
  7. INSTALL FRONT FLOOR FOOTREST LH  (See INSTALLATION )
  8. INSTALL LOWER CENTER PILLAR GARNISH LH  (See INSTALLATION )
  9. INSTALL FRONT SEAT OUTER BELT ASSEMBLY LH  (See INSTALLATION )
  10. INSTALL LAP BELT OUTER ANCHOR COVER LH  (See INSTALLATION )
  11. INSTALL REAR DOOR SCUFF PLATE LH  (See INSTALLATION )
  12. INSTALL DRIVER SIDE KNEE AIRBAG ASSEMBLY  (See INSTALLATION )
  13. INSTALL LOWER INSTRUMENT PANEL FINISH PANEL SUB-ASSEMBLY  (See INSTALLATION )
  14. INSTALL NO. 1 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY  (See INSTALLATION )
  15. INSTALL SIDE INSTRUMENT PANEL LH  (See INSTALLATION )
  16. INSTALL FRONT DOOR OPENING TRIM COVER LH  (See INSTALLATION )
  17. INSTALL FRONT DOOR SCUFF PLATE LH  (See INSTALLATION )
  18. INSTALL NO. 2 CONSOLE BOX DUCT  (See INSTALLATION )
  19. INSTALL CONSOLE BOX  (See INSTALLATION )
  20. INSTALL CONSOLE BOX REGISTER ASSEMBLY  (See INSTALLATION )
  21. INSTALL REAR ASH RECEPTACLE ASSEMBLY  (See INSTALLATION )
  22. INSTALL FRONT ASH RECEPTACLE ASSEMBLY  (See INSTALLATION )
  23. INSTALL CONSOLE PANEL SUB-ASSEMBLY  (See INSTALLATION )
  24. INSTALL UPPER NO. 2 CONSOLE PANEL GARNISH  (See INSTALLATION )
  25. INSTALL UPPER NO. 1 CONSOLE PANEL GARNISH  (See INSTALLATION )
  26. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY  (See INSTALLATION )
  27. INSTALL FRONT SEAT ASSEMBLY LH  (See INSTALLATION )
  28. INSTALL REAR INNER SEAT TRACK BRACKET COVER LH  (See INSTALLATION )
  29. INSTALL REAR OUTER SEAT TRACK BRACKET COVER LH  (See INSTALLATION )
  30. INSTALL FRONT INNER SEAT TRACK BRACKET COVER LH  (See INSTALLATION )
  31. INSTALL FRONT OUTER SEAT TRACK BRACKET COVER LH  (See INSTALLATION )
  32. INSTALL FRONT SEAT HEADREST ASSEMBLY
  33. INSPECT FRONT SEAT ASSEMBLY  (See INSTALLATION )
  34. INSPECT BRAKE WARNING LIGHT  (See PARKING BRAKE SYSTEM )
  35. INSPECT SRS WARNING LIGHT

    HINT.

    See DIAGNOSIS SYSTEM
