Rear Side Door Window Weatherstrip Replacement

WARNING: This page is about a different car, the 2019 Chevrolet Malibu. However, it is still accessible from the selected car via links, so may be relevant.
GM4213870Courtesy of GENERAL MOTORS COMPANY
Callout Component Name

Preliminary Procedures

  1. Rear Side Door Window Inner Sealing Strip Replacement
  2. Rear Side Door Window Frame Front Applique Replacement
  3. Rear Side Door Window Frame Rear Applique Replacement
  4. Rear Side Door Window Weatherstrip Retainer Replacement
  5. Rear Side Door Window Upper Reveal Molding Replacement
1 Rear Side Door Window Weatherstrip Fastener
2 Rear Side Door Window Weatherstrip
