Installing the component carrier

NOTE: RISK OF DAMAGE
Damage to the surface .
The use of metal-cutting tools (e.g., emery cloths) for cleaning surfaces can damage them and lead to leaks and/or engine damage .

Do not use any metal-cutting tools.

NOTE: TECHNICAL INFORMATION
The sealing surfaces must be free of oil, grease and cleaning agents.

Check centering sleeves (1) in the marked area for damage and replace centering sleeves (1) if necessary.

Courtesy of BMW OF NORTH AMERICA, INC.
Clean sealing surfaces (1) with special tool 0 495 102 (11 4 470) .

Courtesy of BMW OF NORTH AMERICA, INC.
Replace the sealing ring (1) on the component carrier (2) .
Parts: Sealing ring

Courtesy of BMW OF NORTH AMERICA, INC.
Check the sealing rings (1) for damage, replace the coolant lines if necessary.

Courtesy of BMW OF NORTH AMERICA, INC.
Guide in and position the component carrier (1).

Courtesy of BMW OF NORTH AMERICA, INC.
Hand-tighten the bolts (1).

Courtesy of BMW OF NORTH AMERICA, INC.
Hand-tighten the bolts (1).

Courtesy of BMW OF NORTH AMERICA, INC.

Tighten down screws (1).

TIGHTENING TORQUES SPECIFICATION

Coolant pump with function carrier on crankcase
M8x35	Tightening torque	19 Nm

Courtesy of BMW OF NORTH AMERICA, INC.

Tighten down screws (1).

TIGHTENING TORQUES SPECIFICATION

Coolant pump with function carrier on crankcase
M8x35	Tightening torque	19 Nm

Courtesy of BMW OF NORTH AMERICA, INC.

Insert and install the holder (2).

Tighten down screw (1).

TIGHTENING TORQUES SPECIFICATION

Standard screw connection M6
M6	Tightening torque	8 Nm

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: TECHNICAL INFORMATION
Make sure that the connections are locked correctly. The locks must engage audibly.

Connect and lock coolant line (1).
The coolant lines (1) must engage audibly.
Secure the clamp (2).

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: TECHNICAL INFORMATION
Make sure that the connections are locked correctly. The locks must engage audibly.
Connect and lock coolant line (1).
The coolant lines (1) must engage audibly.
Connect connectors (2) and lock.
The connector (2) must engage audibly.

Courtesy of BMW OF NORTH AMERICA, INC.

Follow-up work

Refer to INSTALLING AIR CONDITIONING COMPRESSOR .
Refer to PARTIALLY INSTALLING AUXILIARY COOLANT PUMP .
Refer to PARTIALLY INSTALLING THE AIR CONDITIONING CONDENSER .
Refer to INSTALLING ALTERNATOR .
Refer to INSTALLING THE DRIVE BELT FOR ALTERNATOR .
Refer to INSTALLING THE CHARGE AIR DUCT FOR CYLINDERS 4-6 .
Refer to INSTALLING THE CHARGE AIR DUCT FOR 1-3 CYLINDERS .
Refer to INSTALLING FAN COWL .
Refer to INSTALLING THE REAR TOP CROSS CONNECTION .
Refer to INSTALLING FRONT-END STRUT ON LEFT AND RIGHT .
Refer to INSTALLING FRONT CROSS CONNECTION .
Refer to INSTALLING THE SEAL FOR THE HOOD GASKET LEFT AND RIGHT .
Refer to INSTALLING THE COVER IN THE ENGINE COMPARTMENT AT TOP LEFT AND RIGHT .
Refer to INSTALLING THE COVER PANEL OF THE ENGINE COMPARTMENT ON THE REAR LEFT AND RIGHT .
Refer to INSTALLING THE LEFT AIR DUCT .
Refer to INSTALLING RIGHT AIR DUCT .
Refer to FILLING THE HIGH-TEMPERATURE COOLING SYSTEM WITH THE VACUUM FILLING EQUIPMENT .
Refer to CONNECTING NEGATIVE BATTERY CABLE OF THE SYSTEM BATTERY .
Refer to VENTING THE HIGH-TEMPERATURE COOLANT SYSTEM .
Refer to EVACUATING AND CHARGE CONDITIONING .
Refer to CHECKING THE HIGH-TEMPERATURE COOLING SYSTEM FOR WATERTIGHTNESS .
Refer to INSTALLING THE FRONT BOTTOM RIGHT WHEEL ARCH COVER .
Refer to INSTALLING FRONT UNDERBODY PROTECTION .
Refer to INSTALLING THE CENTER UNDERBODY PROTECTION .
