Electric mirror, function - GF88.79-P-0006FL
WARNING: This page does not describe the selected car, but rather 33 other vehicles, including the 2016 Mercedes-Benz E63 S AMG, 2016 Mercedes-Benz E400, 2016 Mercedes-Benz E350, 2016 Mercedes-Benz E300, and 2016 Mercedes-Benz E250. However, it is still accessible from the selected car via links, so may be relevant.
MODEL 212
Electric outside mirrors, general
In order to adapt to the different driving situations, the outside mirrors are electrically adjustable. The mirror glasses can be heated additionally.
The electric outside mirror function contains the following partial functions, which are described in separate documents:
- Garage door opener function (with code (232) Garage door opener or with code (231) Garage door opener at frequency of 284-390 MHz)
- Mirror glass adjustment of left/right outside mirror
- Heat left/right outside mirror
- Passenger side outside rearview mirror park position (with code (275) Electrically adjustable front seats, memory package)
- Folding left/right outside mirror (with code (249) Automatically dimming inside and outside mirrors including folding outside mirrors without code (494) USA version)
- Automatic dimming outside and inside mirror (with code (249) Automatically dimming inside and outside mirrors including folding outside mirrors without code (494) USA version or with code (249) Automatic dimming inside and outside mirror (driver) with code (494) USA version)
| Garage door opener, function | MODEL 212 with CODE 231 (Garage door opener) MODEL 212 with CODE 232 (Garage door opener with frequency 284-390 MHz) | GF68.05-P-0001FL | |
| Mirror lens adjustment left/right outside mirror, function | GF88.79-P-2008FL | ||
| Heat left/right outside rearview mirrors function | GF88.79-P-2000FL | ||
| Passenger-side outside mirror park position, function | MODEL 212 with CODE 275 (Electrically adjustable front seats memory package) | GF88.79-P-2006FL | |
| Fold left/right outside mirror, function | MODEL 212 with CODE 249 (Automatically dimming inside rearview mirror and outside mirror including fold-in outside mirrors) without CODE 494 (US version) | GF88.79-P-2002FL | |
| Automatic dimming outside mirror and inside rearview mirror, function | MODEL 212 with CODE 249 (Automatic dimming inside rearview mirror and outside mirrors) with CODE 494 (US version) MODEL 212 with CODE 249 (Automatically dimming inside rearview mirror and outside mirror including fold-in outside mirrors) without CODE 494 (US version) | GF88.79-P-2010FL |
