Subsequent work for air guide in luggage compartment

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2013 Porsche 911, 2012 Porsche 911, 2011 Porsche 911, 2010 Porsche 911, and 2009 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Installation Position Air Guide In Luggage Compartment
G09830226Courtesy of PORSCHE CARS NORTH AMERICA, INC.
  1. → Installing wiper link ; → Installing cowl panel cover ; → Installing Cover ; → Installing battery cover ; → Installing instrument panel
  2. → Installing Cover ; → Installing battery cover
  3. → Installing front luggage compartment cover ; → Installing Cover ; → Installing battery cover
  4. → Installing front luggage compartment cover
