Front Oil Seal Replacement: Notes

WARNING: This page is about a different car, the 2003 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative battery cable.
  2. Remove the plug hole plate.
  3. (See PLUG HOLE PLATE REMOVAL/INSTALLATION .)
  4. Remove the spark plugs. (See SPARK PLUG REMOVAL/INSTALLATION .)
  5. Remove the cylinder head cover. (See CYLINDER HEAD COVER INSTALLATION NOTE .)
  6. Remove the drive belt. (See DRIVE BELT REPLACEMENT .)
  7. Remove the front drive shaft (RH) from the joint shaft. (See REMOVAL & INSTALLATION .)
  8. Remove the Crankshaft Position (CKP) sensor.
  9. (See CYLINDER HEAD TEMPERATURE SENSOR .)
  10. Remove in the order indicated in the figure.
    Fig 1: Removing/Installing Crankshaft Position Sensor
    G01929578Courtesy of MAZDA MOTORS CORP.
  11. Install in the reverse order of removal.
