Removing the control module
WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Do not touch the terminal pins on the control module with fingers. Static electricity may damage components in the control module.
Remove:
- the center console according to Rear center console .
- the four screws (A) for the control module bracket.
- take out the control module
- disconnect the control module connector (B)
- the control module.
NOTE:
Always check that the control module and cable harness connector pins and sockets are undamaged and that these have not been pressed out of their locking positions. Damaged or loose pins or sockets may cause a fault.
