Remove/Install Lower Center Cover For Instrument Panel - AR68.10-P-1498SR

MODEL 453

Courtesy of MERCEDES-BENZ USA

	Remove/install
1	Remove center console		AR68.20-P-2000SR
2.1	Remove center mounting console reinforcement	Model 453 with code J58 (Center console with drawer) Model 453 with code J59 (Center armrest)	AR68.20-P-2340SR
2.2	Remove front part of center console below paneling (1)	Model 453 with code J56 (Centre console)
3	Unscrew bolts (2)
4	Unclip paneling (1)	: Check retaining dips (3) for damage. Mounting wedge for damage Replace corresponding retaining dips (3)	Figure
5	Install in the reverse order

Fig 1: Identifying Mounting Wedge (110 589 03 59 00)

Courtesy of MERCEDES-BENZ USA
