Removing and installing lock for glove compartment

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2005 Porsche 911, 2004 Porsche 911, 2003 Porsche 911, 2002 Porsche 911, and 2001 Porsche 911. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Removing And Installing Glove Compartment Lock - As Of MY 2002

Courtesy of PORSCHE OF NORTH AMERICA, INC.

GLOVE COMPARTMENT LOCK REMOVAL/INSTALLATION PROCEDURE - AS OF MY 2002

No.	Designation	Qty.	Removal	Installation
1	Removing lid for glove compartment	1	See REMOVING LID FOR GLOVE COMPARTMENT .	See INSTALLING LID FOR GLOVE COMPARTMENT .
2	Fastening screws	2	Unscrew fastening screws -2- . See Fig 1 .	Screw in fastening screws -2- . See Fig 1 .
			Information: The lock for the glove compartment can not be removed from the handle
3	Handle with lock for glove compartment	1	Remove lock for glove compartment -3- . See Fig 1 .	Position the lock for the glove compartment -3-1-2- . See Fig 1 .
