65 77 720 Removing and installing (replacing) left B-pillar sensor (Cooper Convertible)
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2021 MINI Cooper, 2020 MINI Cooper, 2019 MINI Cooper, 2018 MINI Cooper, and 2017 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:
Read and comply with NOTES
on protection against electrostatic discharge (ESD protection)!.
WARNING:
Observe the NOTE
airbag safety regulations!
Failure to observe correct procedures can deploy the airbag and cause injuries.
Preliminary work needed:
- Disconnect BATTERY GROUND LEAD
- Remove side TRIM PANEL .
Removal:
Unfasten plug connection (1) and disconnect.
Remove screw (2).
Remove sensor (3).
Installation:
Position sensor (3).
Tighten screw (2).
Tightening torque 65 77 3AZ .
Join and lock plug connection (1).
Required reworking:
- Connect BATTERY GROUND LEAD.
- Install side TRIM PANEL .
