51 43 015 Removing and installing / replacing rear left or right lower section of side trim (Z3 Roadster, M Roadster)

WARNING: This page is about a different car, the 2002 BMW Z3 and 2001 BMW Z3. However, it is still accessible from the selected car via links, so may be relevant.

Removing and installing rear upper section of side trim panel, refer to 51 43 010 REMOVING AND INSTALLING/REMOVING REAR LEFT OR RIGHT UPPER SECTION OF SIDE TRIM PANEL (Z3 ROADSTER, M ROADSTER) .

Removing and installing rocker panel cover strip (inside), refer to 51 47 000 REMOVING AND INSTALLING/REPLACING ENTRANCE COVER STRIP (INTERIOR), FRONT LEFT OR RIGHT (Z3 ROADSTER, M ROADSTER, Z3 COUPE, M COUPE) .

Version with Hi-Fi system:

Unfasten plug connection (1).

Only replace:

Unfasten screw connection (2) and take off loudspeaker (3).

Fig 1: Removing Screw Connection

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: The convertible top lid must be closed to remove the side trim panel (4).

Partially unfasten cover (1) and edge protector (2). Unfasten screws (3) and pull lower section of side trim (4) upward/forward over the belt anchor (5).

Fig 2: Removing Cover And Edge Protector

Courtesy of BMW OF NORTH AMERICA, INC.
