51 32 170 Removing and installing/replacing door window glass, front left or right

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2017 BMW M6, 2017 BMW 650i xDrive, 2017 BMW 650i, 2017 BMW 640i xDrive, and 2017 BMW 640i. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

51 3 240

WARNING: Danger of injury.
Carry out repair work on the power window regulator only when the power window motor is de-energized.

Necessary preliminary tasks:

Remove SOUND INSULATION IN FRONT DOOR
Remove OUTER WEATHER STRIP

Loosen hook screws (1) with special tool 51 3 240 on ring gear.

Fig 1: Identifying Hook Screws And Special Tool (51 3 240)

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Slacken hook screw on ring gear (1) until it can be easily twisted out at the inner star (2).

Fig 2: Identifying Inner Star On Ring Gear Hook Screw

Courtesy of BMW OF NORTH AMERICA, INC.

'If necessary, open door window glass (1) until hook screws (2) are accessible.

IMPORTANT: Danger of injury.
Disconnect plug connection (3) at power window motor (pinch hazard).

Release hook screws (2) (turn in clockwise direction).

Fig 3: Identifying Door Window Glass, Screws, And Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Door window glass (3) remove for purposes of clarity.

Raise holder (1) at tab (2) and remove door window glass (3) in upward direction.

Fig 4: Removing Door Window Glass

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Make sure door window glass (1) is correctly seated on holder (2) and window guide (3).

Adjust DOOR WINDOW GLASS .

Carry out function check on power window regulator and anti-trap mechanism.

If necessary, NORMALIZE power window regulator.

Fig 5: Identifying Door Window Glass, Holder And Guide

Courtesy of BMW OF NORTH AMERICA, INC.
