26 11 051 Replacing flexible disk for front propeller shaft

WARNING: This page is about a different car, the 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove propeller shaft from transmission and center bearing

NOTE: To protect universal joints, tie back propeller shaft in area of center mount.

Release screws and remove flexible disc (1) from propeller shaft.

IMPORTANT: Replace shiny ZNS bolts and self-locking nuts.

Tightening torque and angle of rotation: 26 11 1AZ , see 26 11 PROPELLER SHAFT COMPLETE .

Installation:

Arrows (3) on circumference of flexible disk must point to flange arms (2).
Grip mounting bolts of flexible disk at propeller shaft flange at nuts and tighten down at bolt heads.

Fig 1: Identifying Flexible Disc With Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Check centering mount.

Replace damaged centering mount .

Grease centering mount.

Fig 2: Locating Grease Area On Centering Mount

Courtesy of BMW OF NORTH AMERICA, INC.
