Used Car Check (Young Stars) - AP00.20-P-0085A

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2023 Mercedes-Benz CLA45 AMG, 2023 Mercedes-Benz CLA35 AMG, 2023 Mercedes-Benz CLA250, 2022 Mercedes-Benz CLA45 AMG, and 2022 Mercedes-Benz CLA35 AMG. However, it is still accessible from the selected car via links, so may be relevant.

Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 461, 463

G16047775Courtesy of MERCEDES-BENZ USA
U
Completed
[X]		   Input condition not OK: ⓧ
AIR FLOW DOWN     AIR FLOW DOWN
  General
    IMPORTANTTo be performed by the service advisor.
□ Check vehicle for any unresolved service measures. If problems are determined,
↓
conduct unresolved service measures.
IMPORTANT After obtaining special order.		 ◦
□ If the vehicle needs to be moved, pay attention to engine and transmission operation.  If problems are determined,
↓
Perform fault detection and extended diagnosis.
IMPORTANT After obtaining special order.		 ◦
  Vehicle exterior
□ Check condition of vehicle exterior.   ◦ AP60.00-P-6048U
□ Check condition of windshield.   ◦ AP67.10-P-6750A
□ Check exterior lighting for proper operation.   ◦ AP82.10-P-8252EW
□ Check windows for cracks, stone chipping, opacity and any other damage, and enter into table. IMPORTANT Vehicle glazing, Outside mirrors,
Headlamp and rear lamp covers.		 ◦
  Check condition of wiper blades.   ◦ AP82.30-P-8253G
□ Check and correct headlamp adjustment.   ◦ AP82.10-P-8249U
□ Check due date for main inspection. IMPORTANT Enter due date for main inspection here:
If due date of main inspection is ≤ 21 months,
↓
Perform main inspection.		 ◦
  Vehicle interior
□ Check warning and function indicator lamps in instrument cluster.   ◦ AP54.30-P-5449U
□ Check interior lighting for proper operation.   ◦
□ Check horn for proper operation.   ◦
□ Check windshield wipers, windshield washer system and, if necessary, headlamp cleaning system for proper operation.   ◦ AP82.30-P-8249U
□ Read out fault memory and then delete. Model 117, 156, 164, 166, 169, 171.4, 172, 176, 197.3/4, 203, 204, 207, 209, 211, 212, 216, 218, 219, 221, 231, 242, 245, 246, 251, 292, 461
Model 463 up to model year 2019		 ◦ AD00.00-P-2000-04A
    Model 118, 177, 243, 247   AD00.00-P-2000-06MFA
    Model 167   AD00.00-P-2000-06ME
    Model 190, 205, 213, 217, 222, 253
Model 463 as of model year 2019		   AD00.00-P-2000-04B
    Model 257, 290, 293   AD00.00-P-2000-06FR
    Model 238   AD00.00-P-2000-06LWO
□ Check kilometer reading for plausibility. IMPORTANT Maintenance history/service booklet plausible.
Vehicle degree of wear relative to kilometer reading plausible.
Readout of fault memory plausible.		 ◦
□ Check operating instructions and service booklet for completeness and condition.   ◦
□ Check date when next service is due. IMPORTANT Enter due date for service here:
If the time remaining until the next service is s 7500 km (4500 mi) or 6 months,
↓
bring service forward.		 ◦
□ Check function of all electrical and mechanical components and special equipment.   ◦
    Equipment-dependent.
IMPORTANT Locks, Central locking, Power windows, Soft top or Vario roof operation, Seat adjustment and heating, Mirrors, Seat belts, Steering wheel locking, Heater and A/C system, Radio and communication systems, Caps and flaps on stowage boxes/trays, Cup holders.
□ Check vehicle's interior equipment for condition, soiling and any bad odors. Equipment-dependent.
IMPORTANT Seats, Trim, Floor covering, Roof paneling.		 ◦
  Trunk
□ Check luggage compartment or cargo area for damage, wear and soiling.   ◦
    Equipment-dependent.
IMPORTANT Trim, Flaps.
□ Check content of trunk or load compartment or condition and completeness.   ◦
    Equipment-dependent.
IMPORTANT Hazard warning triangle, Vehicle tool kit, Trailer hitch, EASY-PACK load-securing kit.
□ Check TIREFIT tire sealant. Vehicle with TIREFIT.
Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293
Model 463 with code LQ0 (G650 Landaulet)
Model 463 with code MUK2 (USA or Canada vehicle model designation)
Model 463 with code ZQ0 (G 50 0 4x42)
IMPORTANT Enter expiration date here:
IMPORTANT Replace TIREFIT, invoice as additional operation.		 ◦ AP40.10-P-4054R
□ Check/correct tire pressure spare wheel and enter set tire pressure into table.   ◦
    Vehicle with spare wheel.
    Model 117, 118, 156, 164, 166, 167, 169, 172, 176, 177, 190, 197.3/4, 204, 205, 207, 212, 213, 216, 217, 218, 221, 222, 230, 231, 238, 242, 245, 246, 247, 251, 253, 257, 290, 292, 293
Model 463 as of model year 2019		   AP40.15-P-4061A
    Model 171, 203, 209, 211, 219   AP40.15-P-4061B
    Model 243   AP40.15-P-4061EQ
    Model 461
Model 463 up to model year 2019		   AP40.15-P-4060G
□ Check expiration date of first-aid kit (soft sided).   ◦
    Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 461, 463
    Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 463   AP68.00-P-6850EW
    IMPORTANT Enter expiration date here:
IMPORTANT Replace first aid bag, invoice as an additional operation.
□ Check that included charging cables are in good condition and are not damaged.   ◦
    Model 118, 166, 167, 169, 177, 205, 213, 222, 242, 243, 247, 253, 290, 293   AP54.10-P-5459U
□ Engine compartment
Check all visible parts in engine compartment for damage and fluid loss.		   ◦
    Model 117, 156, 169, 176, 242, 245, 246   AP00.20-P-0055AK
    Model 118, 177, 247   AP00.20-P-0055I
    Model 164, 171, 172, 197.3/4, 203, 204, 207, 209, 211, 212, 216, 218, 219, 221, 230, 231, 251   AP00.20-P-0055EW
    Model 166, 292   AP00.20-P-0055D
    Model 167   AP00.20-P-0055H
    Model 190   AP00.20-P-0055B
    Model 205   AP00.20-P-0055C
    Model 213, 238, 253 (except 253.99), 257, 290   AP00.20-P-0055E
    Model 217, 222   AP00.20-P-0055A
    Model 243   AP00.20-P-0055M
    Model 253.99   AP00.20-P-0055G
    Model 293   AP00.20-P-0055J
    Model 461   AP00.20-P-0053AB
    Model 463 up to model year 2019   AP00.20-P-0055F
    Model 463 as of model year 2019   AP00.20-P-0055GA
□ Check engine oil level.   ◦
    Engine 111, 112, 113, 133, 139, 152, 156, 157, 159, 176, 177, 178, 254, 256, 260, 264, 266, 270, 271, 272, 273, 274, 275, 276, 277, 278, 279, 282, 607, 608, 611, 612, 626, 628, 629, 640, 642, 646, 647, 648, 651, 654, 656   AP18.00-P-1848U
□ Check main circuit coolant level in expansion reservoir.   ◦ AP20.30-P-2049U
□ Windshield washer system: Check/correct fluid level. IMPORTANT When using cleaning compounds for summer/winter, and depending on the ambient temperature, observe the mixing ratio.   AP82.35-P-8249U
□ Underside of vehicle
Check all major assemblies, systems and component parts for visible damage, wear and fluid loss.		   ◦ AP60.00-P-6049U
  Tires, wheels
□ Check tires, disk wheels as well as spare wheel for condition, wear and damage as well as ease of movement. ◦
    Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 461, 463
Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245 (except 245.286), 246, 247, 251, 253, 257, 290, 292, 293, 461, 463		 AP40.10-P-4048U
□ Correct tire pressure and enter set tire pressure in table.   ◦
    Model 117, 118, 156, 164, 166, 167, 169, 172, 176, 177, 190, 197.3/4, 204, 205, 207, 212, 213, 216, 217, 218, 221, 222, 230, 231, 238, 242, 245, 246, 247, 251, 253, 257, 290, 292, 293
Model 463 as of model year 2019		   AP40.15-P-4061A
    Model 171, 203, 209, 211, 219   AP40.15-P-4061B
    Model 243   AP40.15-P-4061EQ
    Model 461
Model 463 up to model year 2019		   AP40.15-P-4060G
  Brake system
□ Perform brake test and enter result in table. Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 243, 245, 246, 247, 251, 253, 257, 290, 292, 293, 461, 463
Model 117, 118, 156, 164, 166, 167, 169, 171, 172, 176, 177, 190, 197.3/4, 203, 204, 205, 207, 209, 211, 212, 213, 216, 217, 218, 219, 221, 222, 230, 231, 238, 242, 245 (except 245.286), 246, 247, 251, 253, 257, 290, 292, 293
Model 463 as of model year 2019		 ◦ AP42.00-P-4290BA
    Model 243   AP42.00-P-4290EQ
    Model 461
Model 463 up to model year 2019		   AP42.00-P-4290G
  Concluding work
□ Conduct a road test.
  Miscellaneous
□ Enter any other faults into table.   ◦
BRAKE VALUES

  Left Right
Front
Rear
Parking brake
TIRE CONDITION

  Right front Left front Right rear Left rear
Condition OK.
Condition not OK.
SET TIRE PRESSURE IN KPA OR PSI (100 KPA = 1 BAR)

  Front axle Rear axle Spare tire
kPa/psi
REMARKS

Item Comment




DAMAGE

Item Damage





MISCELLANEOUS
