Replace Front Oil Seal: Notes

WARNING: This page is about a different variant/trim than selected.
  1. Remove using the procedure shown in the figure below.
G16700931Courtesy of MAZDA MOTORS CORP.
PART NAME DESCRIPTION

Procedure Part name
1 Crankshaft pulley lock bolt
(See FRONT OIL SEAL REMOVAL NOTE )
(See FRONT OIL SEAL INSTALLATION NOTE )		 49 G028 205 Replacement part Engine oil
