Front Oil Seal Installation Note

WARNING: This page is about a different variant/trim than selected.
  1. Apply engine oil to the inner surface of the new front oil seal.
  2. Insert the front oil seal into the engine front cover by hand.
  3. Tap the front oil seal in using the SST.
G16700933Courtesy of MAZDA MOTORS CORP.
SYMBOL AND CONTENT DESCRIPTION

Symbol Content
0-1 mm {0.00-0.03 in}
49 G028 205
