Front Drain Hose Removal
FRONT DRAIN HOSE REMOVAL
1. Remove the battery cover. Removal and Replacement
2. Disconnect the negative battery cable.
3. Remove the following parts:
a. Front door Front Door Removal/Installation
b. Sail garnish Service and Repair
c. Front scuff plate inner Front Scuff Plate Removal/Installation
d. Rear scuff plate Rear Scuff Plate Removal/Installation
e. B-pillar lower trim B-Pillar Lower Trim Removal/Installation
f. Front seat belt upper anchor installation bolt Front Seat Belt Removal/Installation
g. B-pillar upper trim B-Pillar Upper Trim Removal/Installation
h. Rear package tray lid Service and Repair
i. Sub-trunk Service and Repair
j. Third-row seat Third-Row Seat Removal/Installation
k. Rear header trim Rear Header Trim Removal/Installation
l. Trunk end trim Trunk End Trim Removal/Installation
m. Third-row seat belt lower anchor installation bolt Third-Row Seat Belt Removal/Installation
n. Cargo compartment light Service and Repair
o. Trunk side trim
p. Second-row seat belt upper anchor installation bolt Second-Row Seat Belt Removal/Installation
q. C-pillar trim C-Pillar Trim Removal/Installation
r. Map light Service and Repair
s. Sunvisor Service and Repair
t. Assist handle Service and Repair
u. Headliner Headliner Removal/Installation
v. Front side trim Front Side Trim Removal/Installation
w. Side panel (passenger's side) Side Panel Removal/Installation
x. Side wall Side Wall Removal/Installation
y. Center console (Vehicles with rear vent) Center Console Removal/Installation
z. Selector lever knob (ATX) Front Console Removal/Installation
aa. Shift lever knob (MTX) Front Console Removal/Installation
ab. Front console Front Console Removal/Installation
ac. Glove compartment Service and Repair
ad. Dashboard under cover Dashboard Under Cover Removal/Installation
ae. Hood release lever Service and Repair
af. Lower panel Lower Panel Removal/Installation
ag. Knee bolster Dashboard Removal/Installation
ah. Center panel module (vehicles with audio unit) Center Panel Module Removal/Installation
ai. Center panel (vehicles without audio unit) Center Panel Removal/Installation
aj. Selector lever component Service and Repair
ak. Driver-side air bag module Driver-Side Air Bag Module Removal/Installation
al. Steering wheel Service and Repair
am. Combination switch Removal and Replacement
an. Meter hood Meter Hood Removal/Installation
ao. Lower column cover Service and Repair
ap. Instrument cluster Removal and Replacement
aq. Steering shaft Service and Repair
ar. A-pillar trim A-Pillar Trim Removal/Installation
as. Climate control unit Climate Control Unit Removal/Installation - Full-Auto Air Conditioner Climate Control Unit Removal - Manual Air Conditioner Climate Control Unit Installation - Manual Air Conditioner
at. Rear heat duct (1) Service and Repair
au. Windshield wiper arm and blade Windshield Wiper Arm and Blade Removal/Installation
av. Cowl grille Cowl Grille Removal/Installation
aw. Dashboard Dashboard Removal/Installation
4. Disconnect the front drain hose from the sunroof frame.
5. Remove the front drain hose from the clips.
6. Pull the front drain hose into the vehicle interior and remove the front drain hose.
