Wiper Switch: Removal

  1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
    CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
  2. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
  3. REMOVE NO. 3 STEERING WHEEL COVER LOWER (See  REMOVAL  )
  4. REMOVE NO. 2 STEERING WHEEL COVER LOWER (See  REMOVAL  )
  5. REMOVE STEERING PAD (See  REMOVAL  )
  6. REMOVE STEERING WHEEL ASSEMBLY (See  REMOVAL  )
  7. REMOVE STEERING COLUMN COVER (See  REMOVAL  )
  8. REMOVE SPIRAL CABLE WITH STEERING SENSOR (See  REMOVAL  )
  9. REMOVE WINDSHIELD WIPER SWITCH ASSEMBLY
    1. Disconnect the connector.
    2. Detach the claw and remove the wiper switch.
      NOTE: If the claw is pushed with excessive force, it may break.
      Fig 1: Identifying Windshield Wiper Switch Assembly
      G04021830Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
