Lifter(S), Hydraulic: Installation
WARNING: This page is about a different car, the 2017 Jeep Cherokee. However, it is still accessible from the selected car via links, so may be relevant.
- Verify that the hydraulic lifters are at least partially full of oil. There should be little or no plunger travel when the hydraulic lifter is depressed.NOTE:
If the hydraulic lifters are being reused, reassemble them into their original locations.
- Install the hydraulic lifter(s)NOTE:
If the rocker arms are being reused, reassemble them into their original locations.
- Install the rocker arm(s). Refer to INSTALLATION .
- Install the camshaft. Refer to INSTALLATION
.
- Install the VVAA. Refer to ASSEMBLY, VARIABLE VALVE ACTUATION, INSTALLATION .
- Install the cylinder head cover. Refer to INSTALLATION .
- Connect the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), connect the IBS connector to the negative battery cable.
