Air Cleaner Outlet Front Duct Replacement
WARNING: This page is about a different car, the 2017 Cadillac ATS. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the aero shutter front bumper fascia air deflector. Refer to Aero Shutter Front Bumper Fascia Air Deflector Replacement (Sedan)Aero Shutter Front Bumper Fascia Air Deflector Replacement (Coupe) . |
|
| 1 | Air Cleaner Outlet Front Duct Procedure Release the retaining tabs and rotate forward to remove. |
