Body - Interior & Exterior: Interior: Headliner: Removal
- Disconnect and isolate the negative battery cable. If equipped with an Intelligent Battery Sensor (IBS), disconnect the IBS connector first before disconnecting the negative battery cable. Wait two minutes for the system capacitor to discharge before further service.
- Remove the front overhead console. Refer to CONSOLE, OVERHEAD, FRONT, REMOVAL .
- Remove screw from behind overhead console.
- Remove the grab handles. Refer to HANDLE, GRAB, ROOF, REMOVAL .
- Remove the coat hooks. Refer to HOOK, COAT, REMOVAL .
- Remove the visors. Refer to VISOR, REMOVAL .
- Disconnect the front electrical connector (2) and separate the wire harness (1) from the A-pillar.
- Remove the A-pillar trim panels. Refer to PANEL, A-PILLAR TRIM, REMOVAL .
- Remove the B-pillar trim panels. Refer to PANEL, B-PILLAR TRIM, UPPER, REMOVAL .
- Remove the C-pillar trim panels. Refer to PANEL, C-PILLAR TRIM, REMOVAL .
- Remove the D-pillar trim panels. Refer to PANEL, D-PILLAR TRIM, REMOVAL .
- Remove rear view mirror and disconnect wire harness connectors for mirror, humidity and rain sensors. Refer to MIRROR, REARVIEW, REMOVAL .
- Disconnect the rear electrical connectors (1).
- Remove the two rear push pin fasteners (2).
- For vehicles with a sunroof, separate the hook and loop fasteners (2) around the outside of the sunroof opening.CAUTION:
Be careful not to crease the headliner.
- Remove left cowl trim to gain access to solvent disconnect fitting. Refer to PANEL, COWL TRIM, SIDE, REMOVAL .
- Disconnect all electrical connectors and the washer solvent hose.
- With a helper, remove the headliner through the liftgate opening.
