Body - Interior & Exterior: Interior: Visor: Removal

NOTE:

This process is to be followed whether a sun visor is being replaced or not!

Disconnect and isolate the battery negative cable.
Remove the media system monitor, if equipped. Refer to MONITOR, MEDIA SYSTEM, REMOVAL .
Remove 'A' Pillar trim panels on both sides. Refer to PANEL, A-PILLAR TRIM, REMOVAL .
Remove 'B' pillar upper & lower trim panels on both sides. Refer to PANEL, B-PILLAR TRIM, UPPER, REMOVAL .
Remove the coat hooks, if equipped.
Remove front & rear grab handles on both sides. Refer to HANDLE, GRAB, ROOF, REMOVAL .
Remove the rearview mirror . Refer to MIRROR, REARVIEW, REMOVAL .
Remove center overhead console fastener & drop console. Refer to CONSOLE, OVERHEAD, FRONT, REMOVAL .

Courtesy of CHRYSLER GROUP, LLC
Remove both inboard sun visor fasteners and supports.

Courtesy of CHRYSLER GROUP, LLC
Extend both sun visors toward the center of vehicle.
Position the inboard sun visor support rod and install a tie strap (3) both sun visors (2) to the overhead center console's roof mounted black console support bracket (1).

Courtesy of CHRYSLER GROUP, LLC

NOTE:
Visors should be rotated downward.
Remove visor screw covers (2).

Courtesy of CHRYSLER GROUP, LLC
Remove all visor fasteners (2) from both sides.

Courtesy of CHRYSLER GROUP, LLC
For vehicles with a sunroof, separate the hook and loop fasteners (2) around the outside of the sunroof opening.
CAUTION:
Be careful not to crease the headliner.
Pull down the headliner.

Courtesy of CHRYSLER GROUP, LLC
Remove the white colored 'top hat' clip (4) from the roof header carefully, it will need to be re-used (if the clip breaks a new one will be required for installation).
NOTE:
Whether the sun visor was replaced or not, make sure the visor is aligned correctly and tie strapped to the overhead console's mounting bracket before continuing.
Disconnect the electrical connector (2) and remove the visor as necessary.
