Auxiliary Blower Motor Resistor Assembly Replacement (Passenger Van)

WARNING: This page is about a different car, the 2019 GMC Savana 3500, 2019 GMC Savana 2500, 2019 Chevrolet Express 3500, and 2019 Chevrolet Express 2500. However, it is still accessible from the selected car via links, so may be relevant.
GM4846274Courtesy of GENERAL MOTORS COMPANY
Callout Component Name

Preliminary Procedure

  1. Remove the appropriate rear bench seats. Rear Bench Seat Removal and Installation (With Bench Seat) , or Rear Bench Seat Removal and Installation (With Split Bench)
  2. Body Rear Corner Garnish Molding - Left Side - Remove - Body Rear Corner Garnish Molding Replacement
  3. Body Rear Corner Trim Panel - Left Side - Remove - Body Rear Corner Trim Panel Replacement - Left Side
1 Auxiliary Blower Motor Resistor Bolt [2x]
CAUTION:

Refer to Fastener Caution .


Tighten
1.9 N.m (1 lb ft)
2 Auxiliary Blower Motor Resistor
Procedure
Disconnect the electrical connector.
