Rear Side Door Check Link Replacement

WARNING: This page is about a different car, the 2017 Chevrolet Spark. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Front Side Door Check Link

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedures Move the window to the full up position Remove the rear side door trim. Refer to Rear Side Door Trim Replacement . Remove the rear door speaker. Refer to Radio Rear Side Door Speaker Replacement . Remove the water deflector.
1	Rear Side Door Check Link Bolt to Body CAUTION: Refer to Fastener Caution . Tighten 22 N.m (16 lb ft)
2	Rear Side Door Check Link Bolt (Qty: 2) Tighten 9 N.m (80 lb in)
3	Rear Side Door Check Link Assembly
