Hood Primary Latch Bracket Replacement

Fig 1: Identifying Hood Primary Latch Bracket & Bolts

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedures Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement . Remove the front bumper fascia upper support. Refer to Front Bumper Fascia Upper Support Replacement . Remove hood latch. Refer to Hood Primary and Secondary Latch Replacement .
1	Hood Primary Latch Bracket Bolt (Qty: 5) CAUTION: Refer to Fastener Caution . Tighten 10 N.m (89 lb in)
2	Hood Primary Latch Bracket Procedure Disconnect the harness from the bracket.

Callout

Component Name

Preliminary Procedures

Remove the front bumper fascia. Refer to Front Bumper Fascia Replacement .
Remove the front bumper fascia upper support. Refer to Front Bumper Fascia Upper Support Replacement .
Remove hood latch. Refer to Hood Primary and Secondary Latch Replacement .

Hood Primary Latch Bracket Bolt (Qty: 5)

CAUTION:

Tighten
10 N.m (89 lb in)

Hood Primary Latch Bracket
Procedure
Disconnect the harness from the bracket.
