Driver Seat and Passenger Seat Cushion Heater Replacement

WARNING: This page is about a different car, the 2008 Buick LaCrosse and 2008 Buick Allure. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: View Of Front Seat Cushion Heater Element

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Fastener Tightening Specifications: Refer to Fastener Tightening Specifications . Preliminary Procedures Remove the front bucket seat. Refer to Front Seat Replacement - Bucket . Re-zero the inflatable restraint passenger presence system whenever the seat cushion or any component of the passenger presence system is removed. Refer to Passenger Presence System Rezeroing .
1	Handle, Seat Recliner Refer to Driver Seat and Passenger Seat Recliner Handle Replacement .
2	Cover, Seat Adjuster Finish Cover Refer to Front Seat Adjuster Track Finish Cover Replacement .
3	Cover, Seat Cushion Refer to Front Seat Cushion Cover Replacement .
4	Heater Assembly, Seat Cushion Tip: Disconnect the electrical connector.
