Mounting Bracket, Removing And Installing: Removing

-- Remove the crash bolster. Refer to OVERVIEW - INSTRUMENT PANEL CROSSMEMBER .

-- Refer to BRAKE PEDAL, DISCONNECTING FROM BRAKE BOOSTER .

-- Remove the nuts -arrows- and the footwell trim panel.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolts -1- and remove the steering intermediate shaft -2- from the steering gear -arrow-.

Courtesy of AUDI OF AMERICA, LLC

-- Free up the wire for the accelerator pedal module.

Fig 1: Brake Booster - Tightening Sequence

Courtesy of AUDI OF AMERICA, LLC

-- Remove the nuts -1 through 4- and pull the mounting bracket slightly toward the rear.

-- Disconnect the connectors -2 and 3-.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the expanding rivet -1- and remove the headlamp range control module.

-- Remove the bracket.
