Overview - Bumper Cover, TTRS, Through My 2018
WARNING: This page is about a different variant/trim than selected.
- Front Spoiler-Lower Section
- Removing and Installing. Refer to FRONT SPOILER LOWER SECTION, REMOVING AND INSTALLING .
- Front Spoiler-Upper Section
- Removing and Installing. Refer to FRONT SPOILER UPPER SECTION, REMOVING AND INSTALLING .
- Towing Eye Cover
- Bumper Cover
- Removing and Installing. Refer to BUMPER COVER, REMOVING AND INSTALLING .
- Radiator Grille
- Overview. Refer to OVERVIEW - RADIATOR GRILLE, TTRS .
- Reinforcement Brace
- Lower
- Removing and Installing. Refer to LOWER REINFORCEMENT BRACE, REMOVING AND INSTALLING, TTRS .
- Bolt
- 2 Nm
- Quantity: 6
- End Panel
- The bumper cover
- Removing and Installing. Refer to BUMPER COVER END PLATE, REMOVING AND INSTALLING .
- Lower Molded Foam Part
- Removing and Installing. Refer to Version 3: .
- Lock Carrier Cover
- Removing and Installing. Refer to LOCK CARRIER COVER, REMOVING AND INSTALLING .
- Expanding Rivet
- Quantity: 6
- Center Molded Foam Part
- Removing and Installing. Refer to Version 1: .
- Molded Foam Part
- Removing and Installing. Refer to MOLDED FOAM PART, REMOVING AND INSTALLING .
- Clip
- Clamp
- Quantity: 4
- Bolt
- 2 Nm
- Mount
- For the bumper cover
- To secure the headlamp
- Removing and Installing. Refer to BUMPER COVER MOUNT, REMOVING AND INSTALLING .
- Bolt
- 2 Nm
- Bolt
- Tightening specification -item 1) Bolt -
- Expanding Rivet
- Quantity: 2
- Retaining Strip
- For the wheel housing liner
- Replace after removing.
- Removing and Installing. Refer to WHEEL HOUSING LINER RETAINING STRIP, REMOVING AND INSTALLING .
- Reinforcement Brace
- Side
- Removing and Installing. Refer to SIDE REINFORCEMENT BRACE, REMOVING AND INSTALLING, TTRS, S LINE FROM MY 2019 .
- Bolt
- 4.5 Nm
- Quantity: 3
- Clamp
- Air Intake Grille
- Removing and Installing. Refer to AIR INTAKE GRILLE, REMOVING AND INSTALLING, TTRS THROUGH MY 2018 .
- Side Air Intake Pipe Cap
- Removing and Installing. Refer to SIDE AIR INTAKE CAP, REMOVING AND INSTALLING, TTRS THROUGH MY 2018 .
- Clamp
- Quantity: 4
- Spoiler Lip
- Removing and Installing. Refer to SPOILER LIP, REMOVING AND INSTALLING .
- Bolt
- 2 Nm
- Quantity: 6
