Airbag System, Component Location Overview, Sedan
WARNING: This page is about a different variant/trim than selected.
- Airbag Control Module -J234-
- Overview. Refer to OVERVIEW - AIRBAG CONTROL MODULE .
- Front Passenger Airbag -Disabled- Indicator Lamp -K145-
- Cannot be replaced separately
- Removing and Installing. Refer to COMPONENT LOCATION OVERVIEW - INSTRUMENT PANEL CONTROLS .
- Front Passenger Knee Airbag
- With Front Passenger Knee Airbag Igniter -N296-
- Market-Specific Version
- Overview. Refer to OVERVIEW - FRONT PASSENGER KNEE AIRBAG .
- Front Passenger Airbag Deactivation Key Switch -E224-
- Not for North American Market.
- Front Passenger Airbag
- With Front Passenger Airbag Igniter 1 -N131-
- Market-specific with Front Passenger Airbag Igniter 2 -N132-
- Overview. Refer to OVERVIEW - FRONT PASSENGER AIRBAG .
- Thorax Airbag on Front Passenger Side
- With Front Passenger Thorax Airbag Igniter -N200-
- Overview. Refer to OVERVIEW - FRONT THORAX AIRBAG .
- Front Passenger Head Curtain Airbag
- With Front Passenger Head Curtain Airbag Igniter -N252-
- Overview. Refer to OVERVIEW - HEAD CURTAIN AIRBAG .
- Rear Thorax Airbag on Front Passenger Side
- With Passenger Side Rear Thorax Airbag Igniter -N202-
- Equipped on some models
- Overview. Refer to OVERVIEW - REAR THORAX AIRBAG .
- Rear Thorax Airbag on Driver Side
- With Driver Side Rear Thorax Airbag Igniter -N201-
- Equipped on some models
- Overview. Refer to OVERVIEW - REAR THORAX AIRBAG .
- Driver Head Curtain Airbag
- With Driver Head Curtain Airbag Igniter -N251-
- Overview. Refer to OVERVIEW - HEAD CURTAIN AIRBAG .
- Thorax Airbag on Driver Side
- With Driver Thorax Airbag Igniter -N199-
- Overview. Refer to OVERVIEW - FRONT THORAX AIRBAG .
- Driver Side Airbag
- With Driver Airbag Igniter -N95-
- Overview. Refer to OVERVIEW - DRIVER SIDE AIRBAG .
- Steering Column Electronics Control Module -J527-
- With Spiral Spring -F350-
- Overview. Refer to OVERVIEW - STEERING COLUMN SWITCH MODULE, WITH ELECTRONIC IGNITION SWITCH .
- Airbag Indicator Lamp -K75-
- Integrated in the instrument cluster.
- Cannot be replaced separately
- Instrument Cluster, Removing And Installing. Refer to INSTRUMENT CLUSTER WITH INSTRUMENT CLUSTER CONTROL MODULE -J285-, REMOVING AND INSTALLING / OVERVIEW - INSTRUMENT CLUSTER .
- Driver Side Knee Airbag
- With the Driver Knee Airbag Igniter -N295-
- Overview. Refer to OVERVIEW - DRIVER SIDE KNEE AIRBAG .
