Overview - Knee Airbag, Driver Side
WARNING: This page is about a different variant/trim than selected.
- Connector
- For the Driver Knee Airbag Igniter -N295-
- Disconnecting and connecting. Refer to Removing
- Bolt
- 3 Nm
- Always replace
- Quantity: 2
- Knee Airbag Mount
- From the driver side knee airbag, disconnecting. Refer to DRIVER KNEE AIRBAG, DISCONNECTING FROM MOUNT .
- Nut
- 9 Nm
- Always replace
- Quantity: 2
- Support
- Insert in the mount on the central tube together with the grommet -6-
- Grommet
- Nut
- 9 Nm
- Always replace
- Quantity: 2
- Grommet
- Support
- Insert in the mount on the central tube together with the grommet -8-
- Bolt
- 4.5 Nm
- Always replace
- Quantity: 2
- Driver Side Knee Airbag
- With the Driver Knee Airbag Igniter -N295-WARNING:
Follow all Safety Precautions when working with pyrotechnic components. Refer to SAFETY PRECAUTIONS .
- Removing and installing. Refer to DRIVER SIDE KNEE AIRBAG WITH IGNITER, REMOVING AND INSTALLING .
- Disconnect from the mount. Refer to DRIVER KNEE AIRBAG, DISCONNECTING FROM MOUNT
- With the Driver Knee Airbag Igniter -N295-
