Installing

WARNING: This page is about a different car, the 2014 Volkswagen Touareg, 2013 Volkswagen Touareg, 2012 Volkswagen Touareg, and 2011 Volkswagen Touareg. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

A new lid lock is always delivered with the release cable -2- installed.

Fig 1: Lid Lock. With Components

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Install the lid latch -1- in the lock carrier -arrow a-.

-- Connect the harness connector -7- for the engine hood contact switch depending on the optional equipment.

-- Bolt tightening specification -4- : 12 Nm

-- Bolt tightening specification -6- : 12 Nm

-- Push the caps -5- onto the bolts -4- -arrows b-.

-- Install the release cable -2- in the release cable coupling RELEASE CABLE, DISCONNECTING .

-- Adjust the latch. Refer to HOOD LATCH, ADJUSTING .

Before closing the hood, test the function of the release lever and release cable.
