Radio Frequency Controlled Clock Receiver -J489-, REMOVING AND INSTALLING: Notes

Removal

-- Remove rear bumper cover, refer to REAR BUMPER, REMOVING AND INSTALLING .

-- Remove screws -arrows- and remove Radio Frequency Controlled Clock Receiver -J489- item -2- from rear bumper cover.

-- Disconnect electrical connector -1-.

Fig 1: Identifying Radio Frequency Controlled Clock Receiver -J489-

Courtesy of AUDI OF AMERICA, LLC

Installation

Install in reverse order of removal. Note the following:

-- Install the cover on the rear bumper, refer to REAR BUMPER, REMOVING AND INSTALLING .

If the bumper cover was removed, the Lane Change Assistance Control Module -J769- /Lane Change Assistance Control Module 2 -J770- must be calibrated again LANE CHANGE ASSISTANCE, PREPARING FOR CALIBRATION .
