Adaptation channel 04-Language versions of driver information system

Display on VAS 5051:

Fig 1: VAS 5051 Tester Display - Adaptation Channel 04, Language Versions Of Driver Information System (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "04" in button field -2- for "Adaptation channel 04" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: VAS 5051 Tester Display - Adaptation Channel 04, Language Versions Of Driver Information System (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

1 - Channel 4 read and test
2 - Language
5 - The sliding bar is positioned on the current adaptation value, e.g. 2 = English

The language version is coded via the following adaptation value:

LANGUAGE VERSION CODE

Change adaptation value using the sliding bar. See A - Changing adaptation value using sliding bar: .

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Fill empty spaces with "0".

Example:

Coding: 2 (English)

Keypad input: 00002

Display on VAS 5051 after performed adaptation:

Fig 3: VAS 5051 Tester Display - Adaptation Channel 04, Language Versions Of Driver Information System (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.
