B - Change adaptation value via direct input:
Display on VAS 5051:
Fig 1: VAS 5051 Tester Display - Changing Adaptation Value Via Direct Input (Instrument Cluster) (1 Of 4)
- Press "Keypad" button -3-.
Display on VAS 5051:
Fig 2: VAS 5051 Tester Display - Changing Adaptation Value Via Direct Input (Instrument Cluster) (2 Of 4)
- Enter adaptation value Input value: 0 to 65535
- Enter 5-digit adaptation value in button field -2-. If necessary, insert zeros in front.
Example:
Desired input value: 1
Keypad input: 00001
- Press -Q- button to confirm input.
Display on VAS 5051:
Fig 3: VAS 5051 Tester Display - Changing Adaptation Value Via Direct Input (Instrument Cluster) (3 Of 4)
- 1 - Channel X save
- 2 - Text display of selected channel or No indication
- 4 - original value X new value X
- Confirm new adaptation value by pressing the "take over" button -3-.
Display on VAS 5051:
Fig 4: VAS 5051 Tester Display - Changing Adaptation Value Via Direct Input (Instrument Cluster) (4 Of 4)
- Channel X Value X stored
- End function "10 - Adaptation" by pressing <-- button.
