Adaptation channel 61-Adaptation for comfort system CAN-bus
WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.
Display on VAS 5051:
- Select function "61" in button field -2- for "Adaptation channel 61" and press Q button to confirm input.
Display on VAS 5051:
- Channel 61 read and test
- No indication
- Keypad - only direct input via the keypad is possible
- The sliding bar is positioned on the current adaptation value
NOTE:
- The adaptation values of the table must be entered. See ADAPTATION VALUE .
- When replacing instrument cluster, observe. See Input values for replacing instrument cluster .
Installed control modules (addition of corresponding adaptation values) that participate in the A6 Comfort system CAN-bus are added (See measuring value block. See Measuring value block 130 ).
NOTE:
The instrument cluster, which supports CAN, is not indicated in the measuring value block, but must be added anyway.
ADAPTATION VALUES - COMFORT SYSTEM CAN-BUS
| Equipment | Adaptation value |
|---|---|
| Instrument cluster | 256 |
| Tire pressure | 512 |
Example: Tire pressure control
- Instrument cluster + tire pressure =256 + 512 = 768
- Change adaptation value via direct input. See B - Change adaptation value via direct input: .
- Enter 5-digit adaptation value. Insert zeros in front.
Example:
Desired input value: 768 with tire pressure control
Keypad input: 00768
Display on VAS 5051 after performed adaptation:
- Channel 61
- Value 768 stored
- End function "10 - Adaptation" by pressing <= button.
