Adaptation channel 60-Adaptation for powertrain data-BUS

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Adaptation Channel 60, Adaptation For Powertrain Data-BUS (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "60" in button field -2- for "Adaptation channel 60" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Adaptation Channel 60, Adaptation For Powertrain Data-BUS (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 60
1. read and test
No indication
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value

NOTE:

The adaptation values of the table must be entered. See ADAPTATION VALUES .
When replacing instrument cluster, observe. See Input values for replacing instrument cluster .

Installed control modules (addition of corresponding adaptation values) that participate in the A6 powertrain data BUS are added (See measuring value block. See Measuring value block 125 and Measuring value block 126 ).

NOTE: The instrument cluster, which supports CAN, is not indicated in the measuring value block, but must be added anyway.

ADAPTATION VALUES - POWERTRAIN DATA-BUS

Equipment	Adaptation value
Engine	1
Automatic Transmission	2
Instrument cluster	1024
Self leveling suspension (only allroad quattro)	2048

Example: A6 with manual transmission

Engine + Instrument cluster = 1 + 1024 = 1025

Example: A6 with automatic transmission

Engine + Transmission + Instrument cluster = 1 + 2 + 1024 = 1027

Example: allroad quattro with automatic transmission

Engine + Transmission + Instrument cluster + Self leveling suspension = 1 + 2 + 1024 + 2048 = 3075

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Insert zeros in front.

Example:

Desired input value: 1025 for A6 manual transmission

Keypad input: 01025

Display on VAS 5051 after performed adaptation:

Fig 3: Display On VAS 5051 - Adaptation Channel 60, Adaptation For Powertrain Data-BUS (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 60 Value 1025 stored

End function "10 - Adaptation" by pressing <= button.
