Adaptation channel 42 - minimum mileage performance

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

This function is used to specify a fixed minimum mileage performance in the instrument cluster for the SRI.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Adaptation Channel 42, Minimum Mileage Performance (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "42" in button field -2- for "Adaptation channel 42" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Adaptation Channel 42, Minimum Mileage Performance (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 42
read and test
Minimum value Oil in 1000 Miles
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value, e.g. 10
The minimum mileage performance up to a service will be displayed (here for example 10 represents 10000 miles).

NOTE:

The currently valid specifications can be found in the "Maintenance" book.
See MAINTENANCE .
Input of current specified value is only possible in units of 1000 miles, therefore indication in display also changes in 1000 mile units.

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Insert zeros in front.

Example:

Specification: 10000 miles

Keypad input: 00010

NOTE: The "Save" button does not appear if an incorrect value was entered!

Display on VAS 5051 after performed adaptation:

Fig 3: Display On VAS 5051 - Adaptation Channel 42, Minimum Mileage Performance (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 42

Value 10 stored

End function "10 - Adaptation" by pressing <= button.
