Adaptation channel 40-Distance driven since service

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

This function is used to input the distance in miles since the last service.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Adaptation Channel 40, Distance Driven Since Service (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "40" in button field -2- for "Adaptation channel 40" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Adaptation Channel 40, Distance Driven Since Service (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 40
read and test
Actual value In spec. in 100 Miles
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value, e.g. 8 Distance in miles since last service is indicated (here for example 8 represents 800 miles)

NOTE:

Input of current specified value is only possible in units of 100 miles, therefore indication in display also changes in 100 mile units.
When replacing instrument cluster, observe. See Input values for replacing instrument cluster .

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Insert zeros in front.

Example:

Desired input value: for example, 1000 miles

Keypad input: 00010

NOTE: The "Save" button does not appear if an incorrect value was entered!

Display on VAS 5051 after performed adaptation:

Fig 3: Display On VAS 5051 - Adaptation Channel 40, Distance Driven Since Service (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 40
1. Value 10 stored

End function "10 - Adaptation" by pressing <-- button.
