Adaptation channel 35-Adaptation of the engine speed threshold

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

This function is used to adapt the offset value for the engine speed threshold to the dynamic oil pressure warning.

Display on VAS 5051:

Fig 1: Display On VAS 5051 - Adaptation Channel 35, Adaptation Of Engine Speed Threshold (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "35" in button field -2- for "Adaptation channel 35" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: Display On VAS 5051 - Adaptation Channel 35, Adaptation Of Engine Speed Threshold (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 35 read and test
No indication
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value, e.g. 0

NOTE:

The adaptation value of 0 corresponds to the value set at the factory for the oil pressure warning if the oil pressure drops below 1.2 bar at 1500 RPM.
The adaptation can be performed in four steps (0-1000).
The adaptation value of "250" changes the engine speed threshold to 1750 RPM.
Only direct input via the keypad is possible!
If the value "0" was changed due to a customer complaint, the changed value must be transferred to the new instrument cluster during replacement.

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Insert zeros in front.

Example:

Desired input value: +250 RPM

Keypad input: 00250

Display on VAS 5051 after performed adaptation:

Fig 3: Display On VAS 5051 - Adaptation Channel 35, Adaptation Of Engine Speed Threshold (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 35 Value 250 stored

End function "10 - Adaptation" by pressing <= button.
