Adaptation channel 18-Adaptation of auxiliary heater

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: VAS 5051 Tester Display - Adaptation Channel 18, Adaptation Of Auxiliary Heater (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Select function "18" in button field -2- for "Adaptation channel 18" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: VAS 5051 Tester Display - Adaptation Channel 18, Adaptation Of Auxiliary Heater (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 18 read and test
No indication
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value, e.g. 0

The auxiliary heater is coded via the following adaptation value:

AUXILIARY HEATER ADAPTION CODE

Version	Code
without auxiliary heater	00000
with auxiliary heater, independent from running engine	00001
with auxiliary heater, switches off when engine is off	00010

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Insert zeros in front.

Example:

Coding: 1 (with auxiliary heater, independent of running engine)

Keypad input: 00001

Display on VAS 5051 after performed adaptation:

Fig 3: VAS 5051 Tester Display - Adaptation Channel 18, Adaptation Of Auxiliary Heater (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 18 Value 1 stored

End function "10 - Adaptation" by pressing <= button.
