Adaptation channel 03-Adaptation of fuel consumption display

WARNING: This page does not describe the selected car, but rather 12 other vehicles, including the 2005 Audi allroad, 2004 Audi allroad, 2004 Audi A6, 2003 Audi allroad, and 2003 Audi S6. However, it is still accessible from the selected car via links, so may be relevant.

Display on VAS 5051:

Fig 1: VAS 5051 Tester Display - Adaptation Channel 03, Adaptation Of Fuel Consumption Display (1 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Enter channel number Max. input value = 99

Select function "03" in button field -2- for "Adaptation channel 03" and press Q button to confirm input.

Display on VAS 5051:

Fig 2: VAS 5051 Tester Display - Adaptation Channel 03, Adaptation Of Fuel Consumption Display (2 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 3 read and test
Consumption-display
Keypad - only direct input via the keypad is possible
The sliding bar is positioned on the current adaptation value 100

NOTE:

Value entered must be between 85% and 115%.
Value must be entered in steps of 5%.
If the value "100" was changed due to a customer complaint, the changed value must be transferred when replacing instrument cluster.

Change adaptation value via direct input. See B - Change adaptation value via direct input: .
Enter 5-digit adaptation value. Fill empty spaces with "0".

Example:

Desired input value: 90%

Keypad input: 00090

NOTE: The "Save" button does not appear if an incorrect value was entered!

Display on VAS 5051 after performed adaptation:

Fig 3: VAS 5051 Tester Display - Adaptation Channel 03, Adaptation Of Fuel Consumption Display (3 Of 3)

Courtesy of AUDI OF AMERICA, INC.

Channel 3 Value 90 stored

End function "10 - Adaptation" by pressing <= button.
