Install the Cross Member
WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.
D4192T: If necessary, transfer the bushing for the exhaust pipe mounting.
Clean the mating surfaces thoroughly.
Install the cross member. Install the two front (long) screws. Tighten these two screws by hand.
Position the steering gear housing. Install the control arms loosely on the cross member.
Also replace the locknut for the front pin bolt on the control arm. Do not tighten the locknut yet.
Position the cross member.
- the long screws at the front edge. Tighten to 90 Nm
- the short screws at the rear edge. Tighten to 90 Nm
