Installing the components on the leak diagnostic pump (LDP)
WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the pressure gauge and the governor
- Remove the plug (A) from the leak diagnostic pump (LDP) and reconnect the existing hose. Check that the hose (A) is installed far enough in on the terminal mounting
- Install a new hose clamp and align the hose (A) on the terminal to the filter on the leak diagnostic pump (LDP) housing
- Secure the hose using special tool 9512619 .
