Removing the rear center console

WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Removing/Installing Rear Center Console

Courtesy of VOLVO CARS OF NORTH AMERICA.

Remove:

the rubber underlay (1)
the gear selector panel (2) by pressing in the lugs.

Manual transmissions only:

Press in the clip and remove the gear selector lever boot.

Apply the parking brake.

Remove the guard (3) and screw (4).

Pull the rear center console upwards at the front edge. Remove the gray connector.

Remove the rear center console.
