Replacing Pipes And Hoses: Installation
WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Always use new O-rings.
- In reverse order.
Tightening torques for pipes/hoses
- The bolt on the compressor (to the evaporator): 10 Nm.
The connector on the support: 13 Nm.
The bolt on the evaporator (to the compressor): 10 Nm.
The bolt on the evaporator (to the receiver drier): 10 Nm.
The bolt on the receiver drier (to the evaporator): 10 Nm.
The bolt on the receiver drier (to the condenser): 10 Nm.
The bolt on the condenser (to the receiver drier): 10 Nm.
The bolt on the condenser (to the compressor): 25 Nm.
The bolt on the compressor (to the condenser): 22 Nm.
The swivel on the firewall: 13 Nm.
