Disconnecting the transmission cable
WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.
Remove:
- The retaining clip and washer from the lever
- The mechanical cable from the clip on the bracket for the connectors
- The mechanical cable bracket and the cable from the lever
- The heat deflector plate on the firewall (three nuts).
