Installation, cont.

WARNING: This page is about a different car, the 2004 Volvo S40, 2003 Volvo S40, 2002 Volvo S40, 2001 Volvo S40, and 2000 Volvo S40. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Removing/Installing Engine Compartment Components

Courtesy of VOLVO CARS OF NORTH AMERICA.

Tighten the bearing caps of the return oil pipe on the control system cover.

Install:

transmission connectors
ground cable to the transmission
the mounting of the wiring
the engine speed sensor.
