Bushing Inner Control Arm Upper, Replace
>>
Removal
>>
Removing The Upper Rear Control Arm Bushing
Removing The Upper Rear Control Arm Bushing
Fig 1: Removing Upper Rear Control Arm Bushing
Courtesy of VOLVO CARS OF NORTH AMERICA.
Use tool:
9512923
with
9997054
,
9997035
and
9997036
Install the hydraulic cylinder.
NOTE:
Use threaded rod
9997037
.
Pull the bushing out.
